ROUTER / MODEM
ROUTER WI-FI DUAL-BAND MULTI-FUNZIONE AC750
ROUTER WI-FI DUAL-BAND MULTI-FUNZIONE AC750
CODICE: 4040231
Scheda Tecnica
Descrizione: TD-W8960N è un dispositivo Tutto in Uno che combina le funzioni di modem DSL ad alta velocità, router NAT con 4 porte 10/100 Mbps ed access point wireless, progettato per offrire con un unica soluzione accesso e la condivisione Internet in una rete wireless/cablata.
Grazie al software Easy Setup Assistant, fornito con il CD in dotazione, è possibile configurare facilmente il dispositivo e creare una rete wireless con una velocità 15 volte superiore ed una copertura 5 volte maggiore rispetto ai prodotti tradizionali 11g.
Con TD-W8960N è possibile inoltre creare connessioni sicure verso altre sedi e condividere contenuti e stampanti sulla rete.
CARATTERISTICHE HARDWARE:
Interfaccia: 1 10/100Mbps RJ45 WAN/LAN Port
3 10/100Mbps RJ45 LAN Ports
1 RJ11 Port
Tasto: 1 Power On/Off Button
1 Wi-Fi On/Off Button
1 WPS Button
1 RESET Button
Alimentatore esterno: 9VDC/0.85A
Standard IEEE: IEEE 802.3, 802.3u
Standard ADSL: Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT) , ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs), ITU-T G.995.1
Standard ADSL2: ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.4 (G.lite.bis)
Standard ADSL2 : ITU-T G.992.5
Dimensioni (LxPxA): 7.7×5.1×1.4in.(195×130×36mm)
Tipo di antenna: Omni directional, Fixed
Guadagno antenna: 2×5dBi
CARATTERISTICHE WIRELESS:
Standard wireless: IEEE 802.11b, 802.11g, 802.11n Velocità wireless: Up to 300Mbps
Frequenza: 2.400-2.4835GHz
Potenza di trasmissione: <20dBm (EIRP)
Funzionalità wireless: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Sicurezza wireless: 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption, Wireless MAC Filtering
CARATTERISTICHE SOFTWARE:
QoS (Quality of Service): QoS Remarking based on IPP/ToS, DSCP, 802.1p ATM QoS,Traffic Control(IP QoS) Sicurezza : NAT Firewall, LAN Side Firewall, MAC / IP / URL Filtering, Denial of Service(DoS), SYN Flooding, Ping of Death IP and MAC Address Binding Modalità operative: ADSL Modem Router, Wireless Router
Gestione: Web Based Configuration(HTTP), Remote management,Command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools
DHCP: Server, Client, DHCP Client List,Address Reservation, DHCP relay Port forwarding: Virtual server, Port Triggering, DMZ, ALG Dynamic DNS: DynDns, NO-IP VPN pass-through: PPTP, L2TP, IPSec Pass-through
Protocolli: Support IPv6 and IPv4
Protocolli ATM/PPP: ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed) Bridge (RFC1483 Bridge) PVC – Up to 8 PVCs
Caratteristiche avanzate:
Parental Control
Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt; Network Address Translation (NAT); Port Mapping (Grouping) VLAN, Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS, IGMP snooping V1/2, IGMP Multicast, UPnP Schedulazione wireless: Support 2.4GHz Wireless Schedule Rete ospiti: 2.4GHz Guest Network x 1
Requisiti di sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, 8, 10, MAC OS, NetWare, UNIX or Linux.
Ambiente: Operating Temperature: 0°C-40°C (32°F-104°F) Storage Temperature: -40°C-70°C (-40°F-158°F)
Certificazione: CE, FCC, RoHS
Contenuto della confezione: MODEM TD-W8960N External Splitter
RJ-11 Telephone Cable
RJ-45 Ethernet Cable
Quick Installation Guide
Resource CD
Power Adapter
Annotazioni:
